DIN Connectors - The 7/16 DIN is a higher power and larger connector design. A 50 Ohm impedance design it is a very common connector in cellular, pcs and other broadcast areas of interest. The 7/16 indicator is significant for 7 and 16 mm where the 7mm is the diameter of the inner contact and the 16mm is the diameter of the outer contact measurement. Originally considered a low pim design, the standard 7/16 DIN connector is also spec'ed in a LOW PIM design. The thread is a 29mm by 1.5mm pitch. DIN connectors come is a variety of sizes such as 13-30, 25-58 as well as 1.0/2.3, 1.6/5.6, 4.1.9.5 and 4.3/10 to name a few.
HEX Crimp Die Sizes* for FERRULES for common RF Cables:
.429" - LMR-400, RG-8/11/213/214, Belden 8214/9913
.255" - LMR-240, RG-6/8X/59/62/223
.213" - LMR-195/200, RG-58/142/400
.178" - LMR-100/110, RG-174/178/188/196
*The hex sizes shown are nominal sizes, the user should always inquire if it is not known what size crimp is needed from the manufacturer of the connector. Connectors in this day and time do unfortunately vary in size.
The majority of our brand center RF pins are designed to be soldered and not crimped.
